Silex technology Embedded Intelligent Module SX-560 - Manual (Page 31)

Configuring the SX-560 Silex Page 25
Part Number 140-00192-100
8. You do not need to change any of the settings
in this window. Click the Serial Settings
button to configure the serial port.
9. Select the desired serial port, and configure
the serial port settings so that they match the
settings on your device. For example, if your
device is set for 9600bps, odd parity, and
XON/XOFF flow control, you must change the
settings on the SX-560 to these settings
Click OK when you are finished to return to
the Server Configuration window and then
click OK again.
10. Click OK to save your changes and reset the
SX-560. You can now use the SX-560 on
your network. You may skip the remaining
sections of this chapter, although this
information is useful for future reference.
