Figure 4-3. front panel modem menu tree (3 of 3) – Mocomtech CIM-550 User Manual

Page 52

CiM-550 IP Enabled Satellite Modem

Rev. 2

Front Panel Menus

CD/CIM550.IOM

UTIL
SET-RTC
VFD
ID
MAN-1:1
CENTER-BUF
FAST

STORE/LD

ODU

STORE
LOAD

(SEE SEPARATE
USER'S GUIDE)

COMTECH CIM-550 MODEM
SN 700000007 VER 1.22

PRESS ANY KEY

SELECT: CONFIG TEST INFO
MONIT STORE/LD UTIL ODU

STORE CONFIGURATION TO

LOCATION: 00 (ENTER)

STORE

LOAD

LOAD CONFIGURATION FROM

LOCATION: 00 (ENTER)

EDIT REAL TIME CLOCK:

10;25:05 10/11/02 (ENT)

EDIT DISPLAY BRIGHTNESS:

100% (PRESS ENTER)

EDIT CIRCUIT ID: (ENTER)

------------------------

PRESS ENT TO FORCE THIS

UNIT TO STBY (1:1 ONLY)

PRESS ENTER TO RE-CENTER

THE RECEIVE BUFFER

ENTER NEW CONFIG CODE:

00000000000000000000

TRANSCEIVER CONTROL:

DISABLE ENABLE (ENTER)

CIM-550 Front Panel Menu Tree 3 of 3

Figure 4-3. Front Panel Modem Menu Tree (3 of 3)
