CiM-550 IP Enabled Satellite Modem

Rev. 2

CiM IP Module Checkout & Fault Isolation

CD/CIM550.IOM

421

14.2.3 T

RANSMIT AND

ECEIVE

IF C

ONFIGURATION

Step Procedure

Configure the transmit and receive IF parameters on CiM 1 and CiM 2 via the front panel.

Note: The IF parameters can also be set via console menu, Telnet, web interface and SNMP -

but for this exercise, it is recommended that the front panel be used.

Set the TxPower to minimum level.

Before proceeding to next step, make sure that each CiM is locked to the other CiM.

14.2.4 B

ASIC

IP C

ONFIGURATION

Step Procedure

Launch the terminal emulation program - such as HyperTerminal on Microsoft Windows.

Select the appropriate COM port (to which the DB-9 end of the console cable is
connected) and configure it for:

38,400 bps

8 data bits

no parity

1 stop bit

no hardware flow control

Press return and to bring up the Main menu.
