CiM-550 IP Enabled Satellite Modem
Rev. 2
Connector Pinouts
CD/CIM550.IOM
113
10.3 R
EMOTE
C
ONTROL
C
ONNECTOR
- 9 P
IN
‘D’ T
YPE
M
ALE
Table 10-3. Remote Control Connector - 9 Pin ‘D’ Type Male
Pin
Description
1 Ground
2
EIA-232 Transmit Data (Out)
3
EIA-232 Receive Data (In)
4
Reserved - do not connect to this pin
5 Ground
6
EIA-485 Receive Data B (In)
7
EIA-485 Receive Data A (In)
8
EIA-485 Transmit Data B (Out)
9
EIA-485 Transmit Data A (Out)
10.4 A
UXILIARY
S
ERIAL
C
ONNECTOR
– H
E
1402 3 P
IN
H
EADER
Table 10-4. Auxiliary Serial Connector - He1402 3 Pin Header
Pin
Description
1
EIA-232 Transmit Data
2 Ground
3
EIA-232 Receive Data
