PRIMERGY BX600 S2 Basic Unit 87
Ethernet Switch Blades Cisco Catalyst Blade Switch 3040
The information necessary for configuring and operating the Cisco Catalyst
Blade Switch 3040 can be found in the manual „PRIMERGY BX Blade Server
Systems: Cisco Catalyst Blade Switch 3040“, see
“Related Publications” on
page 165 ).
4 Gigabit Ethernet ports
5 Gigabit Ethernet port indicators (bicolor LEDs)
Dark: No link established.
Glows green: Link established but no activity.
Blinks green: Traffic on an established link.
Glows amber: Port disabled, either error or STP1 disabled.
Glows green or
amber Link fault.
6 SFP module ports
7 SFP module port indicators (bicolor LEDs)
Dark: No link established.
Glows green: Link established but no activity.
Blinks green: Traffic on an established link.
Glows amber: Port disabled, either error or STP1 disabled.
Glows green or
amber Link fault.
