FUJITSU PRIMERGY BX600 S2 - Manual (Page 107)

PRIMERGY BX600 S2 Basic Unit 107
FC Switch Blade Control and Connection Panel
6 LAN speed display (green LED)
Dark: LAN transfer rate 10 Mbit/s
Lights green: LAN transfer rate 100 Mbit/s
7 LAN activity indicator of the FC switch blade (amber LED)
Dark: No connection
Lights: LAN connection is available
Blinks: Data transport
8 Status display of ext. FC ports (2-color LED)
Dark: No signal reception
Flickers green: FC port on-line, data transport
Blinks green: – slow: FC port on-line, but segmented.
– fast: internal loop
Lights amber: Signal reception, but not on-line
Blinks amber: slow (~ 2 sec. intervals): FC port disabled.
fast (~ 0.5 sec. interval): FC port faulty
9 Speed display of ext. FC port (2-color LED)
Dark: FC transfer rate 1Gbit/s
Lights green: FC transfer rate 2Gbit/s
Lights amber: FC transfer rate 4Gbit/s
