Front drive bezels
Follow these steps when removing or installing a front drive bezel.
1 . Prepare the workstation for disassembly ( Preparation for disassembly on page 59 ).
2 . Remove the access panel ( Access panel on page 61 ).
3 . Remove the front bezel ( Front bezel on page 62 ).
4 . Press the two retaining tabs on the inside of the bezel towards the outer edge of the bezel (1) and
pull the bezel blank inwards to remove it (2).
To install a bezel blank, reverse the removal procedure.
