Solving keyboard and mouse problems
If you encounter keyboard or mouse problems, see the documentation that came with the equipment and
to the common causes and solutions listed in the following table.
Table D-9 Solving Keyboard Problems
Keyboard commands and typing are not recognized by the workstation.
Cause Solution
Keyboard connector is not properly connected. 1 . On the Windows Desktop, click Start.
2 . Click Shut Down. The Shut Down Windows dialog
box is displayed.
3 . Select Shut down.
4 . After the shutdown is complete, reconnect the keyboard to
the back of the workstation and restart the workstation.
Program in use has stopped responding to commands. Shut down your workstation using the mouse and then restart
the workstation.
Keyboard needs repairs. See the Worldwide Limited Warranty for terms and conditions.
Wireless device error. 1 . Check the software, if available, for device status.
2 . Check/replace device batteries.
3 . Reset receiver and keyboard.
Workstation is in standby mode. Press the power button to resume from standby mode.
CAUTION: When attempting to resume from standby
mode, do not hold down the power button for more than four
seconds. Otherwise, the workstation will shut down and you will
lose any unsaved data.
Cursor will not move using the arrow keys on the keypad.
Cause Solution
The Num Lock key may be on. Press the Num Lock key. The Num Lock light should not be on if
you want to use the arrow keys. The Num Lock key can be
disabled (or enabled) in Computer Setup.
Table D-10 Solving Mouse Problems
Mouse does not respond to movement or is too slow.
Cause Solution
Mouse connector is not properly plugged into the back of the
workstation.
Shut down the workstation using the keyboard.
1 . Press the Ctrl and Esc keys at the same time (or press the
Windows logo key) to display the Start menu.
2 . Use the up or down arrow key to select Shut Down and
then press the Enter key.
ENWW Solving keyboard and mouse problems 141
