Chapter 11: Controlling a PTZ camera
88 TruVision NVR 10 User Manual
Setting and calling up a shadow tour
The shadow tour command remembers the manually-controlled PTZ dome camera
movement track. One shadow tour can be set up for each PTZ dome camera.
Note: The PTZ dome camera used must be able to support a shadow tour command.
To set up a shadow tour:
1. From the menu toolbar, click PTZ Settings > General .
2. Select the shadow tour from the list.
3. To record a new shadow tour, click and use the directional buttons on the PTZ
control panel to move the camera along the desired path.
4. Click to save the shadow tour.
Note: The shadow tour can be overwritten.
5. Click Back to return to live view.
To call up a shadow tour:
• PTZ control panel:
1. In live view left-click the mouse and select the PTZ Control icon in the quick access
toolbar. The PTZ control panel appears. Select the desired camera from the toolbar.
– Or –
On the front panel, select the desired camera and press Enter on the joystick to call
up the quick access toolbar. The PTZ control panel appears.
2. Scroll the toolbar to Shadow Tour and double-click the shadow tour from the list.
The camera immediately carries out the shadow tour movement.
• Menu toolbar:
1. From the menu toolbar, click PTZ Settings > General .
2. Select the shadow tour from the list and click to start the tour. Click to stop
the shadow tour.
3. Click Back to return to live view.
