Panasonic MINAS A4P Series - Manual (Page 73)

73
[Setting]
Setting
List of 16-bit Positioning Parameters
Parameters for Motor speed
Parameters for Acceleration and Deceleration
00 0 to 6000
<0>
r/min 1st speed Specify a speed when Speed Selection 1 has been selected.
01 0 to 6000
<0>
r/min 2nd speed Specify a speed when Speed Selection 2 has been selected.
02 0 to 6000
<0>
r/min 3rd speed Specify a speed when Speed Selection 3 has been selected.
03 0 to 6000
<0>
r/min 4th speed Specify a speed when Speed Selection 4 has been selected.
04 0 to 6000
<0>
r/min 5th speed Specify a speed when Speed Selection 5 has been selected.
05 0 to 6000
<0>
r/min 6th speed Specify a speed when Speed Selection 6 has been selected.
06 0 to 6000
<0>
r/min 7th speed Specify a speed when Speed Selection 7 has been selected.
07 0 to 6000
<0>
r/min 8th speed Specify a speed when Speed Selection 8 has been selected.
08 0 to 6000
<0>
r/min 9th speed Specify a speed when Speed Selection 9 has been selected.
09 0 to 6000
<0>
r/min 10th speed Specify a speed when Speed Selection 10 has been selected.
0A 0 to 6000
<0>
r/min 11th speed Specify a speed when Speed Selection 11 has been selected.
0B 0 to 6000
<0>
r/min 12th speed Specify a speed when Speed Selection 12 has been selected.
0C 0 to 6000
<0>
r/min 13th speed Specify a speed when Speed Selection 13 has been selected.
0D 0 to 6000
<0>
r/min 14th speed Specify a speed when Speed Selection 14 has been selected.
0E 0 to 6000
<0>
r/min 15th speed Specify a speed when Speed Selection 15 has been selected.
0F 0 to 6000
<0>
r/min 16th speed Specify a speed when Speed Selection 16 has been selected.
16-bit
positioning
PrNo.
Standard default : < >
Setup
range
Unit Title Function/Content
10 0 to 10000
<0>
ms 1st acceleration Specify acceleration when Acceleration Selection 1 has been selected.
Specify an acceleration time in a range between 0 to 3000 [r/min].
* There is a maximum of 10% difference between a calculation value in the
setup and the actual acceleration time.
11 0 to 1000
<0>
ms 1st S-shaped
acceleration
Specify S-shaped acceleration when Acceleration Selection 1 has been
selected. Specify the S-shaped acceleration during acceleration time. For
details, refer to page 131.
If “0” is specified, the linear acceleration time is enabled.
12 0 to 10000
<0>
ms 1st deceleration Specify deceleration when Deceleration Selection 1 has been selected.
Specify a deceleration time in a range between 3000 to 0 [r/min].
* There is a maximum of 10% difference between a calculation value in the
setup and the actual deceleration time.
13 0 to 1000
<0>
ms 1st S-shaped
deceleration
Specify S-shaped deceleration when Deceleration Selection 1 has been
selected. Specify the S-shaped deceleration during deceleration time. For
details, refer to page 131.
If the S-shaped deceleration is set to “0”, the linear deceleration time is enabled.
14 0 to 10000
<0>
ms 2 nd acceleration Specify acceleration when Acceleration Selection 2 has been selected.
Specify an acceleration time in a range between 0 to 3000 [r/min].
* There is a maximum of 10% difference between a calculation value in the
setup and the actual acceleration time.
16-bit
positioning
PrNo.
Standard default : < >
Setup
range
Unit Title Function/Content
