Panasonic MINAS A4P Series - Manual (Page 104)

104
Outline of Setup Support Software, "PANATERM ® "
Log on of the "PANATERM ® " .
1. Once the "PANATERM
® " is installed in the hard disc, you do not need to install every time you log on.
2. Connect the driver to a power supply, the motor and encoder before you log on.
Refer to the instruction manual of supporting OS for start.
Procedure of log on
1) Turn on the power of the computer and log on the supporting OS.
2) Turn on the power of the driver.
3) Click the start bottom of the supporting OS.
(Refer to the instruction manual of supporting OS for start.)
4) Select the "PANATERM ® " with program and click.
5) The screen turns to "PANATERM ® " after showing opening splash for approx. 2sec.
For more detailed information for operation and functions of the "PANATERM ® ", refer to the instruction
manual of the Setup Support Software, "PANATERM ® ".
