10Ć18 Parts and Diagrams

C4699Ć90000

Bail and Overdrive

Reference

on

Drawing

HP Part Number

Quantity

Description

1

0624Ć0617

1

Screw 6Ć9 .937 Plast T15

2

0624Ć0745

2

Screw M4 x 10 Tap T20

3

3050Ć0026

1

Washer 3.2 mm

4

C3190Ć40019

1

Cam Gear

5

C1633Ć40027

1

Engaging Gear

6

C3190Ć80013

1

Cable Spring

7

C3190Ć40021

1

Gear Support

8

0510Ć0083

2

Ring Net .250 OD

9

C3190Ć60131

1

Clutch Assembly (Incl. Rings and Bushings)

10

C3190Ć40055

2

Sideplate Bushing

11

C1633Ć20021

1

Shoulder Screw

12

C1633Ć40019

1

Overdrive Gear

13

3050Ć1415

1

Washer Flat

14

0515Ć1743

1

Screw M4 x 17 Tap T20

15

C3190Ć40020

1

BailĆLift Cam

16

0624Ć0704

6

Screw Plas 6Ć19 x 375
