Page 208
10Ć6 Parts and Diagrams
C4699Ć90000
Top and Back Covers, Electronics, Trailing Cable
Reference
HP Part Number
Quantity
Description
on
Drawing
DesignJet
330/350C
DesignJet
230/250C
1
C4699Ć40003
C4699Ć40003
1
Top Cover (D/A1Ćsize)
C4700Ć40003
C4700Ć40003
1
Top Cover (E/A0Ćsize)
2
C3190Ć60082
C3190Ć60082
1
Back Cover Assy (D/A1Ćsize)
C3191Ć60082
C3191Ć60082
1
Back Cover Assy (E/A0Ćsize)
3
C3190Ć20006
C3190Ć20006
1
TrailingĆCable Guide (D/A1Ćsize)
C3191Ć20006
C3191Ć20006
1
TrailingĆCable Guide (E/A0Ćsize)
4
C1676Ć00055
C1676Ć00055
1
TrailingĆCable metal Clip
5
C3190Ć40024
-
1
Carriage Top
-
C3190Ć40024
1
Carriage Top (DesignJet 250C)
-
C4694Ć40002
1
Carriage Top (DesignJet 230)
6
C3178Ć00030
C3178Ć00030
1
Carriage Label
(DesignJet 350C/250C)
6
C4701Ć00009
-
1
Carriage Label
(DesignJet 330)
7
See page 10Ć2
See page 10Ć2
1
Electronics Module
8
C3190Ć60038
C3190Ć60038
1
Trailing Cable Assy (D/A1Ćsize)
C3191Ć60038
C3191Ć60038
1
Trailing Cable Assy (E/A0Ćsize)
9
C3190Ć40041
C3190Ć40041
3
TopĆCover Hinge
10
0515Ć2282
0515Ć2282
7
Screw M4 x 10 Tap T20
11
1400Ć1021
1400Ć1021
3
TrailingĆCable Plastic Clip
12
C3190Ć00009
C3190Ć00009
1
Cover Plate
13
See page 10Ć28
See page 10Ć28
DRAM SIMM (Optional)
14
C3178Ć60002
-
ROM SIMM (DesignJet 350C)
C4699Ć60104
-
ROM SIMM (DesignJet 330)
-
C3190Ć60152
ROM SIMM
15
0515Ć2246
0515Ć2246
Screw M4 Torx
