230
250C
330
350C
230
250C
Service
Configuration Shift
Ready
330
350C
Ready
Cancel Media
Type
8Ć51 Troubleshooting C4699Ć90000
Printing the Service Configuration Plot
1 To print the service configuration plot:
In service mode 2, load a sheet in portrait orientation.
In normalmode, load a sheet in portrait orientation.
The service configuration plot can be plotted without the need to enter the service
mode. This is because the customer will be requested to plot the service configuration
plot and he will be given the following instructions to plot it without entering the
service mode.
2 When the
Ready
LED lights up:
Hold down the
SHIFT
key and press
Service Configuration
.
Press the
Cancel
and
Media Type
keys together.
The
Ready
light begins to flash and then remains on (steady).
The plotter plots the service configuration plot and ejects the media.
3 Unload the media.
