Page 172: On green, On yellow, Hso supply running, Hso clock fault, Figurea1 utilities leds, Table, Tablea3 ol* led states
Appendix A
sx2000 LEDs
172
Figure A-1
Utilities LEDs
Hot swap
oscillators
(HSO)
System Backplane
RPM
On Green
On
Yellow
HSO Supply running
HSO clock fault
Table A-3
OL* LED States
Description
Power (Green)
OL* (Yellow)
Normal operation (powered)
On
Off
Fault detected, power on
On
Flashing
Slot selected, power on, not
ready for OLA/D
On
On
Power off or slot available
Off
Off
Fault detected, power off
Off
Flashing
Read for OL*
Off
On
Table A-2
Power and OL* LEDs (Continued)
LED
Location
Driven
By
State
Meaning
