User Manual
Aolynk DR814Q ADSL2+ Broadband Router
5 Advanced Configuration
61
Figure 5-23 Host validators page
To add a host validator policy, click to enter the page as below.
Figure 5-24 Configure a host validator
Table 5-6 Description on the items of the host validator
Item Description
Host IP Address
Type in the IP address of the host or network segment to be
restricted.
Host Subnet
Mask Type in the subnet mask of the host or network segment to be
restricted.
Direction
Select the direction of data transmission. Select inbound to
block the inbound data only. Select outbound to block the
outbound data only. Select both to block both inbound data and
outbound data.
Example: To block a host with the IP address 192.168.1.10 in the LAN to access an
external network, and permit the external users to access this host, you can perform
the configuration as below, and then click .
