Huawei DR814Q User Manual
Page 34
User Manual
Aolynk DR814Q ADSL2+ Broadband Router
4 Web-based Basic Configuration
29
Figure 4-23 The applied new IP interface
Follow the above instructions to specify other interfaces.
To delete this interface, select the corresponding [Delete?] check box and click
Caution:
z
You should configure two interfaces (sending and receiving packets respectively) of
DHCP relay in pair. For example, to set the host connected to the LAN port to
communicate with the DHCP server on the WAN side, you need to configure the
iplan and ipwan to be the DHCP relay interfaces concurrently.
z
If no interface is specified, the DR814Q enables the DHCP relay function on all
interfaces by default.
II. Set a DHCP server
To add a DHCP server, type in the IP address (suppose 20.2.0.100) of the DHCP server
in the [New DHCP server IP address] field (see Figure 4-21). This address will be
added to the list of DHCP server IP addresses as below.
