Chapter Ten: Other Configuration Tools TFTP interface 144
Uploading/downloading configuration files
All configuration settings on the DIVA LAN ISDN Modem are stored in configuration files. Using TFTP, you
can access these files to retrieve and set configuration values.
Loading new firmware via TFTP
To upload new firmware to the DIVA LAN ISDN Modem, use your TFTP client software to transfer the
firmware file. For example, under NT, you would issue the following command:
tftp -i 192.168.1.1 put NewImageFile image.elm
Where:
• 192.168.1.1 is the IP address of the DIVA LAN ISDN Modem.
• NewImageFile is the name of the most recent DIVA LAN ISDN Modem image file.
• image.elm is the target file name on the DIVA LAN ISDN Modem.
File Name Access Description
config.bat Write-only A file containing CLI commands. The commands in this file are automatically
executed after being uploaded with TFTP.
Trace commands are not supported by this file. Use trace.bat instead.
trace.bat Write-only Same as config.bat except that it supports trace commands.
results.txt Read-only Contains the results of the last .bat file that was executed.
config.all Read-only Contains the list of commands that define the current active configuration.
Retrieve this file to view the entire configuration of the DIVA LAN ISDN
Modem.
config.bin Read/write Contains a binary image of the current active configuration. You can download
this file to backup the current configuration. (Download as a binary file.)
image.elm Read/write Contains the DIVA LAN ISDN Modem firmware. Write to this file to update the
firmware. After writing is complete, a reset is automatically performed.
Download this file to back up the firmware. (Download as a binary file.)
system.log Read-only The system log contains a record of a variety of events (trace data,
connected/disconnected messages, security-related messages. warning and errors
messages) that have occurred on the DIVA LAN ISDN Modem
.
The log can contain over 15000 entries before it wraps around.
