Chapter Nine: Advanced Installations IP routes 122
In some cases, you may be required to assign a static IP address to a profile. This may occur when connecting
to a corporate network. For example:
This example shows three addresses assigned to the DIVA LAN ISDN Modem: one on the LAN, one for an
Internet connection, and one for a connection to a corporate network.
201.163.1.1
201.163.1.157
Permanent address
Corporate
Network
Corporate
Server
B-channel
B-channel
DIVA LAN ISDN Modem
Internet
ISP
FAULT POWER
DIVA LAN ISDN Modem
ISDN E4/C E1 E2 E3 LINK Ethernet B1 B2 D
192.168.1.1
192.168.1.5 192.168.1.4 192.168.1.3 192.168.1.2
222.182.22.39
Network
ISDN
ISP profile
Corporate profile
Address dynamically assigned by ISP
Permanent address assigned by
corporate network administrator
