Part Names

(14)

(15)

(13)

(5)

(3)

(4)

(2)
(1)

(8)

(7)

(6)

(10)

(9)

(19)

(18)

(20) (21)(22)

(16)

(17)

(23)

(8)

(12)

(11)

(1) Lens mount
(2) Lens lock pin
(3) Grip
(4) EF-S lens mount index
(5) EF lens mount index
(6) Shutter button
(7) Main Dial
(8) Strap mount
(9) Built-in microphones
(10) Built-in flash/AF-assist beam emitter
(11) Speaker

(12) <

V

> Focal plane mark

(13) Mirror
(14) Lens release button
(15) Contacts
(16) Remote control terminal
(17) External microphone IN terminal
(18) Serial number
(19) Tripod socket
(20) Card slot/Battery compartment cover
(21) Card slot/Battery compartment cover

lock

(22) DC cord hole
(23) Body cap
