SIS
™
Programming and Control, cont’d
MVX Plus 128 VGA Matrix Switchers • Programmer’s Guide
4-14
PRELIMINAR
Y
Command/response table for SIS commands (continued)
Command
ASCII command
(host to switcher)
Response
(switcher to host)
Additional
description
View ties, gain, volume, mutes, presets, and DSVP (continued)
View video room preset
confi guration
EX*
*
X1@
*1*1VC
}
X@
1
•X@
2
•
...
•X@
16
•
Vid
]
Show room
X*
, preset
X1!
’s
video confi guration. Show
the input tied to up to 16
outputs assigned to room
X*
.
Command description:
Response description:
room #*room preset #*starting output # (O# - should always be 1)*1(=video)VC
input # (I#) tied to O#1
•
I# tied to O#2
•
I# tied to O#3
•
...
•
I# tied to O#12
•
Vid
]
View audio room preset
confi guration
EX*
*
X1@
*1*2VC
}
X@
1
•X@
2
•
...
•X@
16
•
Aud
]
Show room
X*
, preset
X1!
’s
audio confi guration. Show
the input tied to up to 16
outputs assigned to room
X*
.
Command description:
Response description:
room #*room preset #*starting output # (O# - should always be 1)*2(=audio)VC
input # (I#) tied to O#1
•
I# tied to O#2
•
I# tied to O#3
•
...
•
I# tied to O#12
•
Aud
]
N The response to the ViewFile Directory command differs, depending on whether the command is sent via an
RS-232/RS-422 or Telnet connection or sent via a Web browser connection.
View fi le directory
RS-232/RS-422 port and
Telnet
E
DF
}
fi lename1,date/time,length
]
fi lename2,date/time,length
]
fi lename3,date/time,length
]
•
•
•
•
fi lenamen,date/time,length
]
# of Bytes
•
Left
]]
List user-supplied fi les.
View fi le directory
Web browser
E
DF
}
Var fi le = new array ();
List user-supplied fi les.
File [1] = ‘fi lename1,date1,fi lesize1‘;
File [2] = ‘fi lename2,date2,fi lesize2‘;
File [3] = ‘fi lename3,date3,fi lesize3‘;
•
•
•
•
File [n] = ‘fi lenamen,daten,fi lesizen‘;
File [n+1] = # of Bytes•Left
Erase user-supplied Web
pages/fi les
E
fi lenameEF
}
Delfi lename
]
View DSVP (sync frequency)
X!
LS
X1%,X1%]
Listed as H freq., V freq.
Information requests
Information request
I
V12X08
•
A12X08
]
Request part number
N
60-788-01
]
N There are up to three separate sets of Extron fi rmware that the switcher can report on: the controller fi rmware, which
is the overall control fi rmware; the Ethernet protocol fi rmware, which handles the Ethernet interface; and the latest
optional Extron fi rmware update, which is available at www.Extron.com.
Query controller fi rmware
version
Q
X1(]
Example:
Q
1.23
]
The factory-installed
controller fi rmware version
is 1.23 (sample value only).
