SIS

Programming and Control, cont’d

MVX Plus 128 VGA Matrix Switchers • Programmer’s Guide

4-8

PRELIMINAR

Y

Command/response table for SIS commands (continued)

Command

ASCII command

(host to switcher)

Response

(switcher to host)

Additional
description

Digital Sync Validation Processing

List individual sync
frequency

X!

LS

X1%,X1%]

Listed as H freq., V freq.

Example:

2LS

031.50

,

060.00

]

Input 2 frequency is 31.5
kHz horizontal and 60 Hz
vertical.

N The matrix switcher returns 000.00

,

000.00 if there is no connection or sync frequencies are not applicable.

Video mute commands

RGB mute

X#

*1B

Vmt

X#

*1

]

Mute output

X#

RGB

(video off).

RGB unmute

X#

*0B

Vmt

X#

*0

]

Unmute output

X#

RGB

(video on).

Read RGB mute

X#

B

X(]

1 = mute on, 0 = mute off.

Global RGB mute

1*B

Vmt1

]

Mute all RGB outputs.

Global RGB unmute

0*B

Vmt0

]

Unmute all RGB outputs.

RGB delay

Set RGB delay

EX#

*

X1#

D

}

Out

X#•

Dly

X1#]

Example:

E

13*7D

}

Out13

Dly07

]

Set the RGB interval for
switches to output 13 to 3.5
seconds (7 x 0.5 seconds).

Read RGB delay

EX#

D

}

X1#]

Example:

E

14D

}

05

]

Output 14 interval is 2.5
seconds
(5 x 0.5 seconds).

Audio input gain and attenuation

N The set gain (G) and set attenuation (g) commands are case sensitive.

Set input audio gain to +dB
value

X!

*

X%

G

In

X!•

Aud

X$]

Example:

1*2G

In01

Aud+02

]

Set input 1 audio gain to
+2 dB.

Set input audio attenuation
to -dB value

X!

*

X%

g

In

X!•

Aud

X$]

Increment gain

X!

+G

In

X!•

Aud

X$]

Increase gain by 1 dB.

Example:

5+G

In05

Aud+03

]

Audio input 5 level
incremented from +2 dB to
+3 dB.

Decrement gain

X!

-G

In

X!•

Aud

X$]

Decrease gain by 1 dB.

Example:

7-G

In07

Aud-09

]

Audio input 7 level
decremented from -8 dB to
-9 dB.

Read input gain

X!

G

X$]

Audio output volume

N The table on page 4-9 defi nes the value of each audio volume step.

Set the audio volume to a
specifi c value

X#

*

X&

V

Out

X#•

Vol

X&]

Example:

1*50v

Out01

Vol50

]

Set output 1 volume to 79%.

Increment volume

X#

+V

Out

X#•

Vol

X&]

Increment volume by 1 step.

Example:

1+V

Out01

Vol51

]

Decrement volume

X#

-V

Out

X#•

Vol

X&]

Decrease volume by 1 step.

Read output volume

X#

V

X&]
