SIS

Programming and Control, cont’d

MVX Plus 128 VGA Matrix Switchers • Programmer’s Guide

4-12

PRELIMINAR

Y

Command/response table for SIS commands (continued)

Command

ASCII command

(host to switcher)

Response

(switcher to host)

Additional
description

Save, recall, and directly write presets (continued)

Directly write a room preset

E

+

X*

*

X1@

P

X@

*

X#

!

X@

*

X#

%

X@

*

X#

$ ...

X@

*

X#

&

}

Enter as many ties as are
valid for this model. Tie all (!),
tie RGBHV (&), tie video (%),
and tie audio ($) commands
are all valid.

Rmm

X*•

Spr

X1@]

Example:

+7*3P12*7&11*5$4*5%6*6!

Esc

Brackets are shown to
separate ties for clarity only.
Create preset 3 for room 7,
which ties audio input 12 to
output 7, video input 11 to
output 5, RGBHV input 4
to output 5, and video and
audio input 6 to output 6.

Rmm07

Spr03

]

Executive mode

Lock front panel

1X

Exe1

]

Enable executive mode.

Unlock front panel

0X

Exe0

]

Disable executive mode.

View lock status

X

X(]

Resets

Reset global presets and names

E

ZG

}

Zpg

]

Clear all global presets and
their names.

Reset one global preset

EX1!

ZG

}

Zpg

X1!]

Clear global preset

X1!

.

Reset RGB delays

E

ZD

}

Zpd

]

Reset all RGB delays to 0.0
seconds.

Reset audio input levels

E

ZA

}

Zpa

]

Rest all audio input levels
(gain and attenuation) to 0 dB.

Rest audio output levels

E

ZV

}

Zpv

]

Reset all audio output
levels (volume) to 100% (no
attenuation).

Reset all mutes

E

ZZ

}

Zpz

]

Reset all video and audio
mutes.

Reset room map

E

ZR

}

Zpr

]

Clear all room presets.

Reset individual room

EX*

ZR

}

Zpr

X*]

Clear all presets for room

X*

.

Reset individual room preset

EX*

*

X1@

ZP

}

Zpp

X*

*

X1@]

Clear an individual room
preset and name.

Reset fl ash

E

ZFFF

}

Zpf

]

Reset fl ash memory (erase all
user-supplied fi les).

Reset whole switcher

E

ZXXX

}

Zpx

]

Clear all ties and presets,
reset all audio gains to 0 dB,
and reset volume to 100%.

Absolute reset

E

ZQQQ

}

Zpq

]

Similar to Reset whole
switcher

, plus clear the IP

address to 192.168.254.254
and subnet mask to
255.255.000.000.
