Preliminar y, Operation, cont’d – Extron electronic VGA MATRIX SWITCHERS MVX PLUS 128 User Manual
Page 42

Operation, cont’d
MVX Plus 128 VGA Matrix Switchers • Operation
3-20
PRELIMINAR
Y
5
.
Press and release the Preset button to select group 2 (fi gure 3-32).
C O N T R O L
PRESET
ENTER
ESC
VIEW
Press and release the Preset button to select group 2.
The button lights amber to indicate the selection.
1
3
2
4
Group #
Figure 3-32 — Select an I/O group
6
.
Press and release the input 5 through 8 and output 5 through 8 buttons
(fi gure 3-33).
INPUTS
1
2
3 4
5 6
7 8
9
OUTPUTS
1
2 3 4 5
6 7 8
Press and release the Input 5 through Input 8 buttons.
The selected buttons light.
Press and release the Output 5 through Output 8 buttons.
The selected buttons light.
Figure 3-33 — Assign inputs and outputs
7
.
Do nothing for approximately 30 seconds. The front panel times out and the
switcher exits I/O Group mode.
•
Group 1 consists of inputs 1 through 4 and outputs 1 through 4.
•
Group 2 consists of inputs 5 through 8 and outputs 5 through 8.
