4-13

MVX Plus 128 VGA Matrix Switchers • Programmer’s Guide

PRELIMINAR

Y

Command/response table for SIS commands (continued)

Command

ASCII command

(host to switcher)

Response

(switcher to host)

Additional
description

View ties, gain, volume, mutes, presets, and DSVP

View RGBHV output tie

X#

&

X@]

Example:

15&

27

]

Input 27 RGBHV is tied to
output 15.

View video output tie

X#

%

X@]

Example:

7%

02

]

Input 2 video is tied to output 7.

View audio output tie

X#

$

X@]

Example:

3$

06

]

Input 6 audio is tied to output 3.

View input gain

X@

G

X$]

Example:

4G

-02

]

Gain for input 4 is -2 dB.

View output volume

X@

V

X&]

Example:

7V

55

]

Volume for output 7 is 55%.

View output mutes

E

VM

}

X1$

1

,

X1$

2

, ...

X1$

8

Mut

]

Each

X1$

response is the

mute status of an output,
starting from output 1.

Example:

E

VM

}

02301000Mut

]

Output 2 audio is muted,
output 3 video and audio are
muted, and output 5 video is
muted. All other outputs are
unmuted.

View video global preset
confi guration

EX1!

*1*1VC

}

X@

1

•X@

2

...

•X@

16

Vid

]

Show preset

X1!

’s video

confi guration. Show the
input tied to 16 sequential
outputs (12 are present on
this model), starting from
output 1.

Command description:
Response description:

preset #*starting output # (O# - should always be 1)*1(=video)VC
input # (I#) tied to O#1

I# tied to O#2

I# tied to O#3

...

I# tied to O#12

Vid

]

Example:

1

Output:

Response = tied input:

input 12 tied to output 3

2

3

4

5

6

7

8

08•08•12•08•08•11•00•00

no tied input

input 8 tied to output 4

•--•--•--•--•--•--•--•--•

13 14 15 16

09 10 11 12

outputs do not exist

•Vid

Each position shown in the response is an output: left = output 1, right = output 16.
(Outputs 9 through 16 are not present on the MVX Plus 128.) The number in each
position is the input tied to that output.
In this example, video input 8 is tied to outputs 1, 2, 4, and 5; input 12 is tied to output 3;
and input 11 is tied to output 6. No inputs are tied to outputs 7 and 8.

View audio global preset
confi guration

EX1!

*1*2VC

}

X@

1

•X@

2

...

•X@

16

Aud

]

Show preset

X1!

’s audio

confi guration. Show the
input tied to 16 sequential
outputs (12 are present on
this model), starting from
output 1.

Command description:
Response description:

preset #*starting output # (O# - should always be 1)*2(=audio)VC
input # (I#) tied to O#1

I# tied to O#2

I# tied to O#3

...

I# tied to O#12

Aud

]

Example:

01

Output:

Response = tied input:

input 1 tied to output 3

02 03 04 05 06 07 08

01•01•01•01•02•12•12•00•--•--•--•--•--•--•--•--•Aud

13 14 15 16

09 10 11 12

no tied input outputs do not exist

Each position shown in the response is an output: left = output 1, right = output 16.
(Outputs 9 through 16 are not present on the MVX Plus 128.) The number in each
position is the input tied to that output.
In this example, audio input 1 is tied to outputs 1, 2, 3, and 4; input 2 is tied to output 5,
input 12 is tied to outputs 6 and 7. No input is tied to output 8.
