NEC 40,000-Lumen 4K Laser Installation Projector User Manual
Page 81
64
4. Multi-Screen Projection
❹
Adjust boundaries of a projected image [EDGE BLENDING]
This projector is equipped with an “EDGE BLENDING Function” that makes the edges (boundaries) of the projection
screen indistinguishable.
NOTE:
• Before performing the Edge Blending function, place the projector in the correct position so that the image becomes square in
the appropriate size, and then make optical adjustments (lens shift, focus, and zoom).
• Adjust the brightness of each projector using [REF. LIGHT ADJUST] under [LIGHT MODE]. In addition, use [REF. WHITE BALANCE]
to adjust the [CONTRAST], [BRIGHTNESS] and [UNIFORMITY].
The following procedure shows an example of four projectors in a 2
×
2 layout.
Edge Blending area
Projected area
Projected area
Projected area
Projected area
