62
4. Multi-Screen Projection
Setting TILING
1. Press the MENU button to display the on-screen menu and
select [DISPLAY]
→
[PICTURE SETTING]
→
[MODE].
This displays the [MODE] screen.
2. Select [TILING] using the
▼
/
▲
buttons, and press the ENTER
button.
The display returns to the PICTURE SETTING screen.
3. Select [TILING] using the
▼
/
▲
buttons, and press the ENTER
button.
This displays the [TILING] screen.
4. Set [WIDTH], [HEIGHT], [HORIZONTAL POSITION], and [VERTICAL POSITION]
(1) In the screen for setting the number of horizontal units, select [2 UNITS]. (number of units in the horizontal
direction)
(2) In the screen for setting the number of vertical units, select [2 UNITS]. (number of units in the vertical direc-
tion)
(3) In the screen for setting the horizontal order, select [1st UNIT] or [2nd UNIT].
(look at the screens, the one on the left is the [1st UNIT] while the one on the right is the [2nd UNIT])
(4) In the screen for setting the vertical order, select the [1st UNIT] or the [2nd UNIT].
(look at the screens, the one at the top is the [1st UNIT] while the one at the bottom is the [2nd UNIT])
