31
2. Projecting an Image (Basic Operation)
Adjusting with the remote control
1. Hold the CTL button and press the ECO/L-SHIFT button.
The [LENS SHIFT] screen will be displayed.
2. Press the ▼▲◀ or ▶ button.
Use the ▼▲◀▶ buttons to move the projected image.
TIP:
• The figure below shows the lens shift ranges (projection mode: desktop/front) for 3840 × 2160 images (16:9 aspect ratio) for the
L4K-11ZM, L4K-15ZM and L4K-20ZM lens units. See page 147 for the details of other lenses.
100%V
50%V
50%V
100%H
17%H 17%H
17%H 17%H
Height of projected image
Width of projected image
Description of symbols: V indicates vertical (height of the projected image), H indicates horizontal (width of the projected image).
