154
8. Appendix
❸
Specifications
Model name PH3501QL PH2601QL
Projection method 3 chip DLP ® method
DMD panel Size 1.38", aspect ratio 17:9
Pixels (*1) 8,847,360 (4096 dots × 2160 lines)
Light source Laser Diode
Light output (*2) 35,000 lm (*3) / 40,000 lm (center) 26,000 lm (*3) / 30,000 lm (center)
Contrast ratio (*3) (all white/all
black)
30,000:1 with dynamic contrast
Lens adjustment function Motorized lens shift (vertical/horizontal), motorized zoom, motorized focus
External Control RS-232C (D-sub 9pin) × 1
GP I/O port (D-sub 37 pin) × 1
3D CTL (D-sub 15 pin) × 1
Service USB (Type A) × 1 Remote terminal (Stereo mini jack) × 1
Ethernet port (RJ-45) × 1
Remote interlock port × 1
Power supply voltage For C1 connection (*5) :
Single phase AC 200V-240V 50/60Hz (projector power supply + light power supply)
For C2 connection
(*5) :
Single phase AC 200V-240V 50/60Hz (projector power supply)
Single phase AC 200V-240V 50/60Hz (light power supply)
Power consumption (*4) 4,705 W 3,665 W
Input current (*4) For C1 connection (*5)
projector power supply + light power supply: 30.0A
For C2 connection
(*5)
projector power supply: 4.9A
light power supply: 25.1A
Cooling method Cooling fluid system, Cooling air system
Noise level Less than 55 dB
Installation Orientation: Desktop/front, Desktop/rear, Ceiling/front, Ceiling/rear
Net weight 169 kg (Does not include lens and LV unit)
Dimensions 697 mm (W) × 1180 mm (D) × 455 mm (H) / 27.4 inch (W) × 46.5 inch (D) × 17.9 inch (H)
(Does not including protruding portions, includes foot.)
Environment (*4) Operating temperature: 5 to 40°C
Operating humidity: 20 to 80% (non-condensing)
Storage temperature: -10 to 50°C
Storage humidity: 20 to 80% (non-condensing)
Operating altitude: 0 to 2600 m/8500 feet
Model name NP-LV01BD
Color reproducibility 10-bit color processing (approx. 1.07 billion colors)
Scanning fre-
quency Horizontal 15 kHz, 24 to 153 kHz, conforming to VESA standards
Vertical 24, 25, 30, 48 Hz, 50 to 85 Hz, 100, 120 Hz conforming to VESA standards
Max. display resolution (hori-
zontal × vertical) Digital 4096 × 2160
Input connectors
HDMI Video input HDMI ® Connector type A × 2
Deep Color (color depth): 8-/10-/12-bit compatible
Colorimetry: RGB, YCbCr444, YCbCr422
Supports HDCP
(*6) and 4K
DisplayPort Video input DisplayPort × 2
Data rate: 5.4 Gbps/2.7 Gbps/1.62 Gbps
No. lanes: 1 lane/2 lanes/4 lanes
Color depth: 8 bits, 10 bits
Colorimetry: RGB, YCbCr444, YCbCr422
Supports HDCP
(*6) and 4K
Ethernet/
HDBaseT Video input RJ-45 × 1, 100BASE-TX
Deep Color (color depth): 8-/10-/12-bit compatible
Colorimetry: RGB, YCbCr444, YCbCr422
Supports HDCP
(*6) and 4K
3G/HD/SD-
SDI Video input BNC × 4
Input signals: SMPTE292M, SMPTE424M
Colorimetry: RGB, YCbCr444, YCbCr422
SLOT For mounting separately sold options
Net weight 1.1 kg
Dimensions 320 mm (W) × 220 mm (D) × 81.5 mm (H) / 12.6 inch (W) × 8.7 inch (D) × 3.2 inch (H)
