Diagnostics and Troubleshooting MVI56-PDPMV1 ♦ ControlLogix Platform
User Manual PROFIBUS DPV1 Master
Page 196 of 255 ProSoft Technology, Inc.
March 22, 2011
Byte 2 - Station Status 3 Bits
Bit Description
0 Reserved
1 Reserved
2 Reserved
3 Reserved
4 Reserved
5 Reserved
6 Reserved
7 Extended diagnostic overflow
Byte 3 - Master Address
This byte shows the address of the assigned PROFIBUS Master after
parameterization. If there is an error during the parameterization process, this
byte will display the value FF (hexadecimal).
Byte 4 - Ident Number High
This byte shows the high byte of the specific Ident Number assigned to the
module by the PROFIBUS User Organization.
Byte 5 - Ident Number Low
This byte shows the low byte of the specific Ident Number assigned to the
module by the PROFIBUS User Organization.
