Model PD6210 & PD6310 Batch Controllers Instruction Manual
96
Display Parameter Action/Setting Description
GT rst Grand total reset Program grand total reset mode: auto or
manual
GT tb Grand total time
base Program grand total time base
Gtotal Grand total
password Set or enter password for manual reset
ICal Internal source
calibration Enter internal source calibration (used for
scaling the controller without a signal
source
Ignore Ignore Ignore loop break condition
Info Information Display software and S/N information
Inp 1 Input 1 Calibrate input 1 signal or program input 1
value
Inp 2 Input 2 Calibrate input 2 signal or program input 2
value (up to 32 points)
Input Input Input selection
LatCH Latching Set relay for latching operation (relays as-
signed to rate)
LED t LED test Test all LEDs
Linear Linear Set controller for linear function and select
number of linearization points
Lit Hi Max on little
display Assign digital input to display max on the
small display
Lit HL Max/min little
display Assign the digital input to toggle max/min
on the small display
Lit Lo Min on little dis-
play Assign digital input to display min on the
small display
Little Little display To assign the small display parameters
locd Locked Enter password to unlock controller
Lt-CLr Latching-cleared Set relay for latching operation with manual
reset only after alarm condition has cleared
(relays assigned to rate)
mA 4-20 mA Set controller for 4-20 mA input
mAn Manual To manually control
