Model PD6210 & PD6310 Batch Controllers Instruction Manual
7
INTRODUCTION
The P RO V U
®
PD6210 and PD6310 are easy to use batch controllers ideal for
simplifying independent batch control operations where local control is preferred
to expensive and expansive plant operation systems.
The controller comes programmed for easy front panel start, pause, stop, and
batch size (preset) changes. The bottom display can be programmed to display
rate, grand total, batch count, or preset by cycling the Stop (F3) button.
Single and multi-stage batching is possible with up to 4 on-board relays and 4 with
the external relay module. Each batch control relay may have a unique preclose
amount when used for multi-stage batching.
Manual start batching is default, but automatic batching with a restart after a pro-
grammed time delay from the completion of the last batch, is also possible.
Overrun correction adjusts the closing of the batch control relays to adjust for
inaccuracies from batch to batch. This increases accuracy over time as systems
wear out.
At least two SPDT relays are included for use in batch control or rate alarms.
The batch controllers also share all common P
RO V U Series features, including an
isolated 24 VDC transmitter power supply and Modbus RTU Serial communica-
tions.
ORDERING INFORMATION
Analog Input Standard Models
85-265 VAC
Model 12/24 VDC
Model
Options Installed
PD6210-6R2 PD6210-7R2 2 relays (PD1102*)
PD6210-6R4 PD6210-7R4 4 relays (PD1104*)
PD6210-6R5 PD6210-7R5 2 relays & 4-20 mA output (PD1105*)
PD6210-6R7 PD6210-7R7 4 relays & 4-20 mA output (PD1107*)
*Model number for replacement option card.
Analog Input SunBright Display Models
85-265 VAC
Model 12/24 VDC
Model
Options Installed
PD6210-6H2 PD6210-7H2 2 relays (PD1102*)
PD6210-6H4 PD6210-7H4 4 relays (PD1104*)
PD6210-6H5 PD6210-7H5 2 relays & 4-20 mA output (PD1105*)
PD6210-6H7 PD6210-7H7 4 relays & 4-20 mA output (PD1107*)
*Model number for replacement option card.
