F min 2
[Hz]
T_F min 2
[s]
F min 1
[Hz]
T_F min 1
[s]
F max 1
[Hz]
T_F max 1
[s]
F max 2
[Hz]
T_F max 2
[s]
Default 57.00 0.16 59.30 10.00 60.50 0.16 - -
Range 56.5-57.5 0.1-3.0 57.0-59.8 0.16-300 60.1-60.9 0.16-3.0 60.1-61.0 0.1-3.0
Table 5.4 Default Frequency Trip Levels and Trip Times
NOTICE
The values apply only to IEEE 1547.
5.3 Conformity
International standards MLX series
Directive LVD 2006/95/EC
Directive EMC 2004/108/EC
Safety
IEC 62109-1/IEC 62109-2
UL 1741
UL 508i
Functional safety
IEC 62109-2
UL 1741/IEEE 1547
EMC, immunity
EN 61000-6-1
EN 61000-6-2
EMC, emission
EN 61000-6-3
EN 61000-6-4
CISPR 11 Class B
FCC Part 15
Utility interference EN 61000-3-12
CE Yes
Utility characteristics
IEC 61727
EN 50160
IEEE 1547 UI
Table 5.5 International Standards Compliance
Approvals and certificates are available from the download
area at www.sma.de.
