G317 Eccentric polygon, lateral
G32 Simple thread cycle ... 295
G33 Thread single path ... 297
G35 Metric ISO thread ... 299
G35 metric ISO thread ... 302
G350 Simple longitudinal single-
G351 Simple longitudinal multi-start
G352 Tapered API thread ... 300
G36 Tapping ... 318
G4 Period of dwell ... 369
G40 Switch off TRC/MCRC ... 247
G41 Switch on TRC/MCRC ... 248
G42 Switch on TRC/MCRC ... 248
G47 Safety clearance ... 255
G50 Switch off oversize ... 253
G51 Zero point shift ... 250
G56 Additive zero point shift ... 251
G57 Axis-parallel oversize ... 253
G58 Contour-parallel oversize ... 254
G59 Absolute zero point shift ... 252
G60 Switch off protection
G64 Interrupted feed rate ... 244
G65 Clamping (chuck
G7 Precision stop on ... 369
G701 Rapid traverse to machine
G701 Rapid traverse to machine
G702 Saving/loading contour follow-
G703 Contour follow-up ... 368
G71 Drilling cycle ... 313
G72 Drilling, countersinking ... 315
G720 Spindle
G73 Tapping ... 316
G74 Deep-hole drilling cycle ... 319
G740 Repeat recessing cycle ... 275
G741 Repeat recessing cycle ... 275
G743 Linear pattern, face ... 322
G745 Circular pattern, face ... 323
G746 Circular pattern, lateral
G791 Linear slot, face ... 337
G792 Linear slot on lateral
G793 Contour and figure milling
G794 Contour and figure milling
cycle, lateral surface ... 341
G797 Area milling, face ... 343
G798 Helical-slot milling ... 345
G799 Thread milling, axial ... 326
G8 Precision stop off ... 370
G80, Cycle end / Simple
G801 Engraving on front face ... 366
G802 Engraving on lateral
G803 Engraving in XY plane ... 514
G804 Engraving in the YZ
G808 Hobbing ... 518
G809 Measuring cut ... 283
G81 Simple longitudinal
G810 Longitudinal roughing ... 262
G82 Simple face roughing ... 410
G820 Face roughing ... 265
G830 Contour-parallel
G835 Contour-parallel with neutral
G840 Contour milling ... 346
G841 Area milling—roughing (Y
G842 Area milling—finishing (Y
G845 Pocket milling—roughing (Y
G846 Pocket milling—finishing (Y
G85 Undercut cycle ... 304
G851 Undercut according to DIN
509 E with cylinder
machining ... 306
G852 Undercut according to DIN
509 F with cylinder
machining ... 307
G853 Undercut according to DIN 76
with cylinder machining ... 308
G856 Undercut type U ... 309
G857 Undercut type H ... 310
G858 Undercut type K ... 311
G859 Cut-off cycle ... 303
G86 Simple recessing cycle ... 412
G860 Contour-based
G869 Recess turning cycle ... 276
G87 Line with radius ... 413
G870 Recessing cycle ... 279
G88 Line with chamfer ... 413
G890 Contour finishing ... 280
G9 Precision stop ... 370
G901 Actual values in
G903 Lag error in variables ... 370
G904 Read interpolation
G905 C-angle offset ... 379
G908 Feed rate override 100
G909 Interpreter stop ... 371
G916 Traversing to a fixed
G917 Controlled parting ... 382
G919 Spindle override 100 % ... 371
G920 Deactivating zero shifts ... 372
G921 Deactivating zero-point shifts,
G925 Force reduction ... 383
G93 Feed per tooth ... 245
G930 Sleeve monitoring ... 384
G94 Constant feed rate ... 245
G95 Feed per revolution ... 245
G96 Constant surface speed ... 246
G97 Speed ... 246
