HEIDENHAIN MANUALplus 620, CNC PILOT 640 155
2.1
1
Units—Special oper
ations
"Subprogram call" unit
The unit calls the subprogram defined in "L".
Unit name: SUBPROG / Called cycle: Any subprogram
Access to the technology database:
 Not possible
Contour form
L
Subprogram name
Q Number of repetitions
LA-LF Transfer values
LH Transfer value
LN Transfer value—reference to a block number as contour
reference. Is updated during block numbering.
Cycle form
LI-LK
Transfer values
LO Transfer value
LP Transfer value
LR Transfer value
LS Transfer value
LU Transfer value
LW-LZ Transfer values
Further forms: see page 56
 The tool call is not an obligatory parameter in this unit!
 Instead of the text "transfer value," texts can be
displayed that were defined in the subprogram. You can
also define help graphics for every line of the
subprogram (see page 402).
