HEIDENHAIN MANUALplus 620, CNC PILOT 640 461
5.6 Sear
c
h
cy
cles
A Number of points: Maximum number of probing operations
IC Measuring path C: Measuring path of the C axis (in degrees),
starting from the current position. The algebraic sign determines
the probing direction.
AC Nominal value for target position: Absolute coordinate of touch
point in degrees
BD Tolerance +/-: Measurement result range (in degrees) in which
no compensation is applied
KC Compensation offset: Additional compensation value that is
applied to the zero point result
WE Maximum deviation: Probe twice and monitor the dispersion of
the measured values
F Measuring feed rate: Feed rate for probing. If nothing is entered,
the measuring feed rate from the touch probe table is used. If
the entered measuring feed rate F is higher than the one in the
touch probe table, the feed rate is reduced to the value from the
touch probe table.
Q Tool orientation: Orient the touch probe in the programmed
probing direction before each probing operation (machine-
dependent function)
P PRINT outputs
 0: OFF: Do not display measuring results
 1: ON: Display measuring results
H INPUT instead of measurement
 0: Default: Obtain measured values by probing
 1: PC test: Simulate probing cycle on the programming station
AN Log no.: Save measurement results in
"TNC:\table\messpro.mep" table (line numbers 0–99; the table
can be expanded if necessary)
Parameters
