Analog Audio Output
Profile Family 71
If you want to bypass the sample rate converter:
1. In the Digital Audio Input dialog box, click the Sample Rate Converter tab
(Figure 42). By default, the sample rate converter is enabled. The sample rate
converter affects all four channel inputs.
Figure 42. Digital Audio Input dialog box, Sample Rate Converter tab
2. Click Bypass Sample Rate Converter .
NOTE: Do not bypass sample rate conversion unless you are certain
that all inputs and outputs are synchronous.
3. After you have disabled the sample rate converter, click Close or another tab.
Analog Audio Output
In analog audio output, you can change audio channel names, change line
modes for XLR connectors, or adjust individual or group line levels in decibels.
Click
Undo if you want to cancel any changes, or click Help for context-
sensitive Help.
To configure analog audio output:
1. Expand Audio Output , and then click one of the Analog Channels to bring up
