Chapter 2 Using the Profile Configuration Manager
54 Profile Family
Video Output
You can configure either analog composite or serial digital component video
output on your Profile system, depending on which boards are installed.
Analog Composite Video Output
To open the Analog Composite Video Output dialog box, select Video Output
from the configuration tree and click or double-click an analog composite
output from the list, such as Composite-OutA-J11.
Figure 28. Analog Composite Video Output dialog box
Changing the Procamp Adjustments
The Procamp Adjustment group modifies the output signal to compensate for
any irregularities in the signal path. All changes take place immediately.
• Enable Procamp must be checked before anything in this group can be
adjusted. This enables you to setup the Procamp and then disable it without
losing the setup.
