8-48

To do…

Use the command…

Remarks

Enter system view

system-view

Enter Ethernet interface view or

Layer 2 aggregate interface view

interface interface-type

interface-number

Configure the control VLANs for

receiving flush messages

smart-link flush enable

[ control-vlan vlan-id-list ]

Required

By default, no control VLAN exists

for receiving flush messages.

z

Configure all the control VLANs to receive flush messages.

z

If no control VLAN is specified for processing flush messages, the device forwards the received

flush messages without processing them.

z

Make sure that the receive control VLAN is the same as the transmit control VLAN configured on

the smart link device. If they are not the same, the associated device will forward the received

flush messages directly without any processing.

z

Do not remove the control VLANs. Otherwise, flush messages cannot be sent properly.

z

Make sure that the control VLANs are existing VLANs, and assign the ports capable of receiving

flush messages to the control VLANs.

Displaying and Maintaining Smart Link

To do...

Use the command…

Remarks

Display smart link group information

display smart-link group { group-id |

all }

Available in any view

Display information about the received

flush messages

display smart-link flush

Available in any view

Clear the statistics about flush

messages

reset smart-link statistics

Available in user view

Smart Link Configuration Examples

Single Smart Link Group Configuration Example

Network requirements

As shown in

Figure 8-2:
