SS7 Programmer’s Manual for SPCI2, SPCI4 and CPM8 Issue 2
Page 40
Message Format:
MESSAGE HEADER
FIELD NAME
MEANING
type MGT_MSG_CONFIG0
(0x7F10)
id
0
src Sending module’s module_id
dst MGMT_TASK_ID
(0x8e)
rsp_req
used to request a confirmation
hclass
0
status
0
err_info
0
len
68
PARAMETER AREA
OFFSET SIZE
NAME
0
2
config_type (Must be set to 2)
2 2 flags
4 2 l1_flags
6 2 l2_flags
8 2 max_sif_len
10 2
l3_flags
12 4
pc
16 2
ssf
18 2
up_enable
20 2
link0_flags
22 2
link0_slc
24 4
link0_adj_pc
28 2
link0_stream
30 2
link0_timeslot
32 2
link1_flags
34 2
link1_slc
36 4
link1_adj_pc
40 2
link1_stream
42 2
link1_timeslot
44 2
link2_flags
46 2
link2_slc
48 4
link2_adj_pc
52 2
link2_stream
54 2
link2_timeslot
56 2
link3_flags
58 2
link3_slc
60 4
link3_adj_pc
64 2
link3_stream
66 2
link3_timeslot
