H103
Digit 4 : HV Test
Target Voltage Offset
Digit 4 : EBOND Test
Current Level
‘0’ 0.00kV
0.0A
‘1’ 0.05kV
0.1A
‘2’ 0.10kV
0.2A
‘3’ 0.15kV
0.3A
‘4’ 0.20kV
0.4A
‘5’ 0.25kV
0.5A
‘6’ 0.30kV
0.6A
‘7’ 0.35kV
0.7A
‘8’ 0.40kV
0.8A
‘9’ 0.45kV
0.9A
‘A’ 0.50kV
1.0A
‘B’ 0.55kV
1.5A
‘C’ 0.60kV
2.0A
‘D’ 0.65kV
2.5A
‘E’ 0.70kV
3.0A
‘F’ 0.75kV
3.5A
‘G’ 0.80kV
4.0A
‘H’ 0.85kV
4.5A
‘I’ 0.90kV
5.0A
‘J’ 0.95kV
6.0A
‘K’ 1.00kV
7.0A
‘L’ 1.05kV
8.0A
‘M’ 1.10kV
9.0A
‘N’ 1.15kV
10.0A
‘O’ 1.20kV
12.5A
‘P’ 1.25kV
15.0A
‘Q’ 1.30kV
17.5A
‘R’ 1.35kV
20.0A
‘S’ 1.40kV
22.5A
‘T’ 1.45kV
25.0A
‘U’ 1.50kV
27.5A
‘V’ 1.55kV
30.0A
‘W’ N/A
32.5A
‘X’ N/A
35.0A
‘Y’ N/A
37.5A
‘Z’ N/A
40.0A
