Test code Tables
Seaward Test codes are an 11-character string where each character
is in the ASCII range ‘0’ to ‘9’ and ‘A’ to ‘Z’. The character count starts
from left to right. The example below shows Z as digit 1 or (character
no. 1) and the integer 1 as digit 2 (character no. 2) and so on.
e.g. Z1234567890
Digit 1 (Character 1) – Test code Type
Digit 1 associates the test code with Seaward Group Ltd. Equipment
Digit 1 : Test code Type
‘Z’
Seaward Group Ltd. Test code
Digit 2 – Test Type
Digit 2 represents the type of test to be performed. On the H102 it also
encodes
the status of H102 c
channel 1 – only relevant if the test code is
at the top of a loop. If no channels are explicitly encoded for use then
channel 1 will be used.
H101
Digit 2 : Test Type
‘0’ Skip
Test
‘1’
AC Hipot 50Hz
‘2’
AC Hipot 60Hz
‘3’ DC
Hipot
‘4’
DC Insulation Resistance
‘5’ – ‘9’
Not Used
‘A’ – ‘Z’
Not Used
