XMap User Guide
270
To Place a Point Object at a Specific Location
Use the following steps to place a waypoint, symbol, text label, or image at a specific
coordinate location.
1. Click the Draw tab.
2. To place a waypoint, click and hold the Track/Waypoint tool and
select the Waypoint tool . Select the waypoint symbol from the
Symbols options. You can also select a different font, style, size and color for
the waypoint name.
OR
To place a symbol, click and hold the MapNote/Text
Label/Symbol/Image tool and select the Symbol tool
. Select the symbol from the Symbol Selection list. You can also select
a different font, style, size and color for the symbol name.
OR
To place a text label, click and hold the MapNote/Text
Label/Symbol/Image tool and select the Text Label tool . Select the
font, style, size, and color from the text style options. A sample of how your
text display appears to the left of the options.
OR
To place an image, click and hold the MapNote/Text
Label/Symbol/Image tool to view its hidden options. Select the Image
tool . Under Images, select an existing image or click Add, browse to an
image, and click Open to add a new image to your Images selection.
3. Select the Coordinate option, or use the Distance and Bearing/Angle
option in conjunction with the Coordinate option, and type the appropriate
coordinates or numbers into the corresponding text boxes to the right of the
text style options box.
4. Click Apply. The point object displays on the map at those coordinates,
distance, and bearing or angle.
5. If you are placing a text label, enter the text and press the ENTER key on
your keyboard or click the map outside of the text label active area when you
are finished.
Moving and Deleting Draw MapNotes
You can add your own MapNotes to a map. MapNotes have a white background that
make them highly visible on the map. They can contain multiple lines of text and can
be moved off of the labeled area without losing their visual links with the points. You
can use MapNotes for directions or explanations.
Notes
• This Help topic describes the steps necessary to move and delete Draw
MapNotes. To show/delete Route MapNotes, see Setting Your Routing
Preferences.
• When you use right-click functionality to add a MapNote, it is light blue unless
it is a blank MapNote.
