background image

XMap User Guide

134

Note This option is grayed out when there are no selections in the
source layer.

Query Results to build buffers around geometries in the source layer

that are contained within the results of the active query.

Note This option is grayed out when there is no active query in the
source layer.

5. Under Output Location, select New Layer or Existing Layer.
6. If you selected the New Layer option in step 5, specify the name of the new

layer in the Layer Name text box. Then, select the database for the new
layer from the Target Database drop-down list or select Other to attach a
new database to add layers to.

OR
If you selected the Existing Layer option in step 5, from the Layer Name

drop-down list, select an existing polygon layer in your workspace that will
include the buffer information.

7. Type the buffer distance in the Distance text box. Then, select the distance

measurement (feet, meters, miles, kilometers, nautical miles) from the drop-

down list.

8. Select the Merge Overlapping Buffer Regions check box if you want to

convert buffer polygons that overlap each other into one continuous polygon.

OR
Clear the Merge Overlapping Buffer Regions check box if you want to

retain the individual buffer polygons even when the buffers overlap.

9. Click OK.

Adding Geometries to a Layer

This Help topic describes features that are available in XMap
GIS Editor and XMap GIS Enterprise.


Use the toolbar to edit existing GIS data or build GIS data in an empty/existing
layer.

Notes

• When you click the Edit Points tool

on the toolbar, the default map

mode, which provides several right-click features when you click the map, is

disabled on the map area (primary, secondary, or both) where the layer is

displayed. To return to the default map mode, click the Navigation tool

on the toolbar.

• While adding polygon or line geometries, you can disable snapping by holding

the ALT key on your keyboard. To enable the measurement information box,
which can display on the map when adding geometries, hold the SHIFT key

while you draw.

• To undo your last action, click the Undo button

on the toolbar. To redo

your last action, click the Redo button

.

• To save all of the changes you make to a layer, click the Manual Commit
