78
Burner Menu
– con tinued –
Operating hours
1. Press button Operating hours in the menu Burner Set-up .
2. To set the limits for gas and oil step 1 se-
lect the green input fields individually.
3. The current value appears in the input
mask. Use the on-screen keyboard to
overwrite or modify the value.
4. To delete the current value press button
at the right side of the value to be deleted.
S etpoint
1. Press button Setpoint in the menu Burner
Set-up .
2. To adjust the temperature setpoints select
the green input fields individually.
3. The current value appears in the input
mask. Use the on-screen keyboard to
overwrite or modify the value.
Operating
hours
Logo
Reset Limit AZL values Name of parameter
Gas
Oil step 1/modul.
Oil step 2
Oil step 3
Total operating
Equipm. energised
Setpoint Logo
Name of parameter
Setpoint W1
Setpoint W2
AZL values Input
Setpoint W3
