– contin ued –

CAN bus connection

The connection to the CANopen equipment is implemented via the CAN interface.

A D-subminiature plug connector in accordance with DIN 41652 must be used for the
connection. Use a multi-core flexible control cable as supply line.

Note that screened multi-core twisted-pair control cable is required as Bus line, e. g.
UNITRONIC

BUS CAN 2x 2 x...mm² or RE-2YCYV-fl 2x 2x ...mm².

UNITRONIC

is a registered trademark of LAPP Kabelwerke GmbH, Stuttgart.

C able leng th

N umber of pairs and conductor size [mm²]

125 m

2 x 2 x 0.34

250 m

2 x 2 x 0.5

335 m

2 x 2 x 0.75

500 m

available on demand (depends on bus configuration)

1000 m

Note

The design and preparation of the data cable is an important factor for the
electromagnetic compatibility (EMC) of SPECTOR

control

Connection should therefore be carried out with special care
(see equipment specification of the display and operating panel HPG-200).
