User Interfaces
– continued –
Description of the input masks
- continu ed -
The mask is used for selecting the type of
manual operation.
In the 2 button menu the controller motors
continuously to the selected end position. The
attained mode of operation is optically
indicated in the previous menu. The selected
mode of operation is indicated by the icon on
the button.
Description of buttons
Button Description
Return to start menu
grey = no alarm activated
Current alarm indication red = alarm acknowledged but still activated
flashing = alarm activated and not acknowledged
Indicate help texts for current page
Indicate maintenance
Indicate datalogs
Indicate quantities
Indicate configuration
Indicate system settings
Indicate password entry
Manual
Operation
Open
Close
