Chapter 3 - Using the Command Line Interface (CLI) 3-45
MN/22137, rev 1 Vipersat Configuration
levels. The information and commands in the menu will vary depending on the
function the target CDD-56X performs in the network. The screen shown in
figure 3-58 is from a unit serving as a Hub with STDMA (burst controller).
Note, however, that the only parameter settings that apply to the CDD-56X are
DPC Enabled, Speed Up EbNo, and Target DPC Address. Because all of the
remaining settings shown in this screen are redundant to those configured in the
satellite modem (CDM-570), they do not apply to the CDD-56X and can be
disregarded.
For comparison, the DPC Configuration screen for a unit operating as a Hub or
Remote with Expansion (SCPC mode) is shown in figure 3-59. Note that only
the applicable settings appear in this screen.
Figure 3-58 DPC Configuration screen (Hub, STDMA)
Figure 3-59 DPC Configuration screen (Hub/Remote, SCPC)
Tip: The DPC feature will not function unless the Outbound IP address is
defined in the STDMA screen for the Hub BC modem.
