Initial Configuration MN/22137, rev 1
2-6 Vipersat CDD-56X Series User Guide
Figure 2-5 Working Mode dialog
5. When the reboot is completed, return to the Feature Configuration menu
and configure the settings for Vipersat STDMA and Auto Switching
according to the table below.
6. Save the settings to flash by entering S at the command prompt.
Set the IP Address
1. From the Main Menu, enter I to access the Interface Configuration menu
screen, then enter E to access the Ethernet Interface screen (figure 2-6).
2. Enter I at the command prompt, and enter the IP address for this unit.
Table 2-2 Vipersat Feature Configuration
Unit Role Vipersat STDMA Auto Switching
Hub Enabled Enabled (optional) Enabled
Hub Expansion Enabled Disabled Disabled
Remote Expansion Enabled Disabled Disabled
