5.3.2.5 MONITOR: PS (Power Supply)
28VDC PS = 27.2
RF Power Supply = 9.1
5.3.2.6 MONITOR: Temp
Amplifier Temp = 45 C
5.3.2.7 MONITOR: FETs
RF FET Q01 : 20mA
RF FET Q02 : 72mA (▲ ▼)
Use the ▲▼ arrow keys to scroll backwards or forwards through the displayed RF Power Field
Effect Transistors (FETs). Note the following:
• For CPA-050 – RF FET Q01 through Q07.
• For CPA-100 – RF FET Q01 through Q11.
• CPA-175/CPA-200 – RF FET Q01 through Q18.
5.3.3 SELECT: Utility
UTILITY: Date/Time CID
PowerMon Firmware RefOsc
Use the arrow keys to select
Date/Time, CID, PowerMon, Firmware, or RefOsc , and then
press ENTER.
5.3.3.1 UTILITY: Date/Time
Edit Real-Time Clock:
12:00:00 24/09/10(◄ ►▲▼E)
To edit the time and date settings of the real-time clock: First, use the ◄ ► arrow keys to
select the digit to be edited, and then use the ▲▼ arrow keys to change the value of that digit.
Press ENTER when done.
Note that in accordance with European convention, the date is shown in DAY-
MONTH-YEAR format.
